Understanding IMC-S/23x Setups

5-27

Publication 999-122 - January 1997

The Unwind Reference value is entered in position units and can be a
positive or negative number up to 9 digits.

Enter the Unwind Reference Point and press ENTER.

Encoder Loss Detection

Each physical axis of the IMC-S/23x can be configured to detect loss
of the encoder feedback signal. The IMC-S/23x asks:

Toggle to

YES

and press ENTER to use encoder loss detection for this

axis. If encoder loss detection is enabled, an encoder loss fault occurs
under either of the following conditions:

5. Both of the differential signals for any encoder channel (A+ and A-,

B+ and B-, or Z+ and Z-) are at the same level (both high or both
low). Under normal operation, the differential signals are always at
opposite levels. The most common cause of this situation is a broken
wire between the encoder and the motion controller.

6. Loss of encoder power or encoder common to the motion controller

or the encoder.

If encoder loss detection is not desired for this axis, toggle to

NO

and

press ENTER to disable encoder loss detection.

Editing the Overtravel
Configuration

For physical

SERVO

axes, after editing the conversion constant, the

IMC-S/23x asks

Toggle to

YES

and press ENTER to set up the overtravel configuration

for this axis.

Unwind Reference Point
(Position Units) = +0

Use Encoder Loss Detection? NO

Edit Overtravel Configuration? NO
