2-12

Introduction

Publication 999-122 - January 1997

Number of

Discrete I/O Bits

12 dedicated inputs,
12 dedicated outputs,
User-defined as shown below:

IMC-S/23x Remote I/O Adapter

Number of User-Defined Discrete I/O Bits

Rack Width

Inputs

Outputs

1/4
1/2
3/4

Full

4

36
68

100

4

36
68

100

Maximum Block

Transfer Length

64 words (128 bytes).

Block Transfer

Data Types

User Variable values,
Axis Data Parameter value,
Axis Data Bit state,
Master Cam Position Point values,
Master Cam Time Point values,
Slave Cam Position Point values,
Axis or System Variable value.

Block Transfer

Data Formats

32-bit (double-word) 2s complement integer,
16-bit (single-word) 2s complement integer,
32-bit (8-digit) signed BCD,
32-bit IEEE floating-point,
Word-swapped 32-bit (double-word) 2s complement integer,
Word-swapped 32-bit (8-digit) signed BCD,
Word-swapped 32-bit IEEE floating-point.
