Troubleshooting

7-5

Publication 999-122 - January 1997

Understanding Status LEDs

Three general purpose status LEDs are provided on the front panel of
the IMC-S/23x. These LEDs (status 0, 1, and 2) indicate the results of
power-up diagnostics.

Table 7.A Status LEDs

* Flashing slow is twice per second, flashing fast is ten times per second.

Understanding the System
OK LED

If the system passes its power-up diagnostics, all three status lights are
off and the System OK LED (CPU Watchdog) is illuminated.

For this LED:

0

1

2

Status of the LED:

Description:

Possible resolution:

Off

Off

Off

Solid

Controller okay. No faults.

None.

On

Off

Off

Solid

Memory fault. Setup or
program checksum error.

Note: This condition is normal after you change
firmware or perform a hardware re-init.
Download the GML diagram and the setups again
and reset the controller.

On

On

Off

Solid

AxisLink initialization failure Reset the control. If the problem persists, return to

the factory for repair.

Off

Off

On

Solid

RIO interface initialization
failure

Reset the control. If the problem persists, return to
the factory for repair.

On

Off

On

Solid

Flex I/O initialization failure

Reset the control. If the problem persists, return to
the factory for repair.

Off

On

On

Solid

Interrupt initialization failure

Reset the control. If the problem persists, return to
the factory for repair.

On

On

On

Solid

Initialization failure

Reset the control. If the problem persists, return to
the factory for repair.

On

Off

Off

Flashing fast*

Dram test #1 failed

Return to the factory for repair.

Off

On

Off

Flashing fast*

Dram test #2 failed

Return to the factory for repair.

On

On

Off

Flashing fast*

Dram test #3 failed

Return to the factory for repair.

Off

Off

On

Flashing fast*

Applications memory
functionality test failed

Return to the factory for repair.

On

Off

On

Flashing fast*

Setup memory functionality
test failed

Return to the factory for repair.

On

Off

Off

Flashing slow*

Serial port test failed

Return to the factory for repair.

Off

On

Off

Flashing slow*

Timer test failed

Return to the factory for repair.

On

On

Off

Flashing slow*

Initialization test failed

Return to the factory for repair.

Off

Off

On

Flashing slow*

Auxiliary I/O test failed

Return to the factory for repair.

On

Off

On

Flashing slow*

CXIC failed

Return to the factory for repair.

Off

On

On

Flashing slow*

DRAM test failed

Return to the factory for repair.

On

On

On

Flashing slow*

Transfer system failed

Return to the factory for repair.
