OPERATOR’S STATION
Display Warnings and Alarms
Informs Operator of abnormal windrower conditions.
Figure 3.66: CDM Display Warnings and Alarms
Display (A) Flashing Alarm Tone Description
BRAKE OFF
Engine running, brake solenoid
not activated
BRAKE ON X Short beep with each flash
Ground speed lever (GSL) out of
N-DETENT, but interlock switch
remains closed to apply brake
BRAKE SW FAILURE X Short beep with each flash
Ignition ON / engine not running,
brake switch and relay closed
CAB-FORWARD SW ON/
ENG-FORWARD SW ON
X Messages flash alternately Both seat switches activated
CENTER STEERING Beeps at 2 per second
GSL or interlock switches not
closed with key ON / engine OFF
DISENGAGE HEADER
RE-ENGAGE <1800
RPM>
X None
R80/R85 - Engine rpm above
1800 when engaging header
ENGINE AIR FILTER X
Single loud tone for 10 seconds:
repeats every 30 minutes until
condition is corrected
Engine air filter requires servicing
169887 82 Revision A
