DESCRIPTION
CAB
Type Spring/shock suspension
Width 63 in. (1600 mm)
Depth 68.3 in. (1735 mm) (at top of window)
Height 64.6 in. (1640 mm)
Dimensions
Volume 125 cu.ft. (3540 L)
Driver Adjustable air-ride suspension, seat belt
Seat
Training Folding, cab mounted, seat belt
Front 31.5 in. (800 mm) Blade
Windshield
Wiper
Rear 22 in. (560 mm) Blade
Heater 24,000 Btu/h (7038 W)
Air Conditioning 28,280 Btu/h (8288 W)
Electrical Outlets One live, two on ignition, one live/keyed
Mirrors One inside (transport), two outside (field)
Radio Two speakers and antenna factory installed: radio Dealer installed
SYSTEM MONITORING
Speeds
Ground (mph or km/h), engine (rpm), knife (spm), disc (rpm), reel (rpm
or mph/km/h), conveyor (Ref. No.)
Header Height, angle, float, header drive load gauge
TIRE OPTIONS
Drive 18.4 – 26 Bar, 18.4 – 26 Turf, 600-65 R28 Bar, 23.1 – 26 Turf,
580/70R26 Turf
Size
Rear 7.5 – 16SL single rib, 10 - 16 front steer tire 16.5L – 16.1 rib implement
flotation, forked caster
Drive Refer to Inflating Drive Wheel Tire, page 393
Pressure
Rear Refer to Inflating Caster Tire, page 400
FRAME AND STRUCTURE
Dimensions Refer to 2.3 Windrower Dimensions, page 34
Frame to Ground (Crop Clearance) 45.7 in. (1160 mm)
Base 9920 lb. (4500 kg)
Max GVW 21500 (9750 kg) Weight
Max CGVW 23,100 lb (10,480 kg)
NG Header Compatibility
A40-D Auger, D50 Harvest Header,
D60 Harvest Header / D65 Draper Up To 40 ft, R80/R85 Rotary Disc
NOTE:
• Specifications and design are subject to change without notice or obligation to revise previously sold units.
• Weights do not include options.
169887 33 Revision A
