Page 169
2. Ensure lock (A) at the base of the steering column is
engaged at cab-forward or engine-forward position.
3. Move ground speed lever (GSL) (B) into N-DETENT.
4. Turn steering wheel until it locks. It may be possible to
move the steering wheel slightly in the locked position.
IMPORTANT:
Do NOT attempt to force the wheel out of locked position
as damage to the traction system may occur.
5. Fasten seat belt.
6. Push HEADER DRIVE switch (C) to ensure it is OFF.
Figure 4.8: Operator Controls
Normal Start
Engine temperature above 60°F (16°C):
WARNING
If starter engages with steering wheel unlocked,
ground speed lever out of NEUTRAL, or header
clutch engaged, DO NOT START ENGINE. See your
Dealer.
1. Set throttle (A) to START position—fully back.
IMPORTANT:
The machine gauges and instruments provide important
information about machine operation and condition.
Familiarize yourself with the gauges and monitor them
carefully during start-up operation. Refer to
.
CAUTION
Check to be sure all bystanders have cleared the area.
2. Sound horn three times.
3. Turn ignition key (B) to RUN position. Single loud tone
sounds, engine warning lights illuminate as a self-test,
and cab display module (CDM) displays “HEADER
DISENGAGED” and “IN PARK”.
4. Turn ignition key (B) to START position until
engine starts, and then release key. CDM displays
programmed header data for 5 seconds if attached,
and then returns to previous display.
Figure 4.9: Operator Console
169887
153
Revision A
