Display (lower or upper line)

Description

##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)

Actual cutting rate in acres (hectares)/hour.

###.# SUB ACRES
###.# SUB HECTARES (if metric)

Area cut since last reset. To reset, display SUB ACRES on lower line,
and hold down program switch until display resets (5–7 seconds).

###### TOTAL ACRES
###### TOTAL HECT (if metric)

Total area cut by machine.

##.## REEL MPH
##.## REEL KPH (if metric)
##.## REEL SENSOR (flashing)

Reel peripheral speed.

Sensor Disabled. MPH or KPH and SENSOR alternate at 1 second
intervals.

##.# DRAPER SPEED

Draper speed (0.0–11.0).

#### KNIFE SPEED
#### KNIFE SENSOR

Knife speed In strokes per minute.
Sensor Disabled. SPEED and SENSOR alternate at 1 second intervals.

##.# HEADER HEIGHT
##.# HEADER SENSOR

Distance setting (00.0–10.0) between cutterbar and ground.
Sensor Disabled. HEIGHT and SENSOR alternate at 1 second
intervals.

##.# HEADER ANGLE
##.# HEADER SENSOR

Angle setting (00.0–10.0). Header relative to ground.
Sensor Disabled. ANGLE and SENSOR alternate at 1 second intervals.

##.# L FLOAT R ##.#
FLOAT SENS DISABLED

Left and right float setting (0.0–10.0).
Sensor Disabled.

### °C or F HYD OIL TEMP
### °C or F HYD SENSOR

Hydraulic oil temperature.
Sensor Disabled. TEMP and SENSOR alternate at 1 second intervals.

LOAD|■■■■| | ####

Bar graph representing hydraulic operating pressure. Full scale
is pre-programmed overload pressure (2500–5000 psi). If sensor
disabled, LOAD does not display

##.# VOLTS

Engine electrical system operating voltage.

SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
##.## REEL MPH
##.# DRAPER SPEED

Displays sub-menu after 2–3 seconds. Press SELECT to cancel.
Scroll through sub-menu display with CDM switch.

KNIFE SPD OVERLOAD

Knife or Disc Speed Drops Below Programmed Value.

The LOAD sensor to monitor knife/conditioner circuit pressure is optional. To monitor reel/auger circuit pressure, relocate
sensor as per Form MD #169031, which is available through your Dealer.
