OPERATOR’S STATION
4. Press SELECT (B) until SET CONTROL LOCKS? is
displayed on the upper line.
• NO/YES is displayed on the lower line.
5. Press right (A) arrow to select YES. Press SELECT (B).
Figure 3.132: Set Control Locks
6. Press SELECT (D) until DRAPER SPEED is displayed
on the upper line.
• ENABLED/LOCKED is displayed on the lower line.
7. Press left (B) arrow to enable DRAPER SPEED
control switch.
Press right (C) arrow to lock DRAPER SPEED
control switch.
8. Press PROGRAM (A) to exit Programming Mode or
press SELECT (D) to proceed to next WINDROWER
SETUP action.
Figure 3.133: Set Draper Control Lock
Activating the Auger Speed Control Lock Out
NOTE:
• This procedure is for A40-D Headers only.
• An auger header MUST be attached to the windrower to perform this procedure. The cab display module
(CDM) automatically adjusts its programming for each header. For more information, refer to 4.5 Attaching
and Detaching Headers, page 202
169887 114 Revision A
