Page 75

3.12

Operator Amenities

The operator’s station includes the following amenities:

Operator’s Console
A - Auxiliary power outlet
B - Utility tray (under armrest)
C - Cigarette lighter
D - Ashtray / cup holder
E - Utility tray

Figure 3.36: Console

Window Shades (Optional)

Retractable window shades (A) can be installed for the front
and rear windows.

MD #B4866

Figure 3.37: Window Shades (Optional)

Auxiliary Outlets

Two auxiliary power outlets are located on either side of
the wiper motor cover/storage tray behind the Operator
(cab-forward mode).

Figure 3.38: Auxiliary Power Outlets

A - Auxiliary Power Outlet

B - Auxiliary Power Outlet

C - Battery Terminal

D - Ground Terminal

E - Switched Terminal

169887

Revision A
