MAINTENANCE AND SERVICING
Figure 5.227: Formed Caster Wheel Tightening
Sequence
Servicing Caster Wheels
Refer to the following procedures:
• Raising Caster Wheel (Formed and Forked), page 402
• Lowering Caster Wheel (Formed and Forked), page 403
• Removing Forked Caster Wheel, page 403
• Installing Forked Caster Wheel, page 404
• Removing Formed Caster Wheel, page 405 Installing Formed Caster Wheel, page 405
Raising Caster Wheel (Formed and Forked)
This procedure is the same for forked and formed caster wheels.
DANGER
Stop engine and remove key from ignition before leaving operator's seat for any reason. A child or even a
pet could engage an idling machine.
1. Park windrower on level ground and block the
drive wheels.
2. Place the ground speed lever (GSL) in N-DETENT (A),
stop the engine and remove the key.
Figure 5.228: GSL Position
169887 402 Revision A
