2 Description
2.1 Definitions
The following terms and acronyms may be used in this manual.
Term Definition
A-Series header MacDon auger header
API American Petroleum Institute
ASTM American Society of Testing and Materials
Bolt A headed and externally threaded fastener that is designed to be paired with a nut
Cab-forward Windrower operation with the Operator and cab facing in the direction of travel
CDM Cab display module on a self-propelled windrower
Center-link
A hydraulic cylinder link between the header and the machine to which it is attached:
It is used to change header angle
CGVW Combined vehicle gross weight
D-Series header MacDon rigid draper header
DWA Double Windrow Attachment
ECM Engine control module
Engine-forward Windrower operation with the Operator and engine facing in the direction of travel
Finger tight
Finger tight is a reference position where sealing surfaces or components are
making contact with each other and the fitting has been tightened to a point where
the fitting is no longer loose
FFFT Flats from finger tight
GSL Ground speed lever
GVW Gross vehicle weight
Hard joint
A joint made with the use of a fastener where the joining materials are
highly incompressible
Header
A machine that cuts and lays crop into a windrow and is attached to a
self-propelled windrower
Hex key
A hex key or Allen key (also known by various other synonyms) is a tool of
hexagonal cross-section used to drive bolts and screws that have a hexagonal
socket in the head (internal-wrenching hexagon drive)
hp Horsepower
ISC Intermediate Speed Control
JIC
Joint Industrial Council: a standards body that developed the standard sizing and
shape for original 37° flared fitting
Knife A cutting device which uses a reciprocating cutter (also called a sickle)
n/a Not applicable
Nut An internally threaded fastener that is designed to be paired with a bolt
N-DETENT The slot opposite the NEUTRAL position on operator’s console
