Avaya P580 User Manual
Page 623
Avaya P550R, P580, P880, and P882 Multiservice Switch User Guide, v5.3.1
19-11
Analyzing Network Performance By Using RMON and Ethernet Statistics
4. Refer to Table 6-122 for an explanation of the fields on the
Port Mirroring Configuration Web page.
Table 6-122. Port Mirroring Configuration Web Page Parameters
Parameter
Definition
Source Port(s)
List of available selections. You can select a particular
source port associated with the selected fabric port. You
can also select all ports.
Note:
To mirror inbound traffic only, select a source
port and a mirror port, not a piggyback port.
Mirror Port
Displays the port from which you want to send the
traffic. This port can be on another module in the
switch. Once a specific port associated with a fabric port
has been designated a mirror port, other ports
associated with that fabric port no longer appear on the
selection list.
Note:
The source port and the mirror port must be
different physical ports.
1 of 3
