Avaya P550R, P580, P880, and P882 Multiservice Switch User Guide, v5.3.1
17-11
Monitoring the Avaya Multiservice Switch
Figure 6-163. Protocol Event Management Dialog Box
5. Refer to Table 6-111 to Configure the Protocol Event
Management dialog box parameters for the specific protocols
that you have Configured on your switch:
Table 6-111. Protocol Event Management Dialog Box Parameters
Column
Heading
Parameter
Fault
Select Enable to display serious errors that can cause
a system crash, for example, panic. The default is
Disable.
Error
Select Enable to display serious errors that will not
cause a system crash but can contribute protocol
problems.
Warning
Select Enable to display non-critical errors. The
default is Disable.
Info
Select Enable to display Event details. The default is
Disable.
