9-108 Avaya P550R, P580, P880, and P882 Multiservice Switch User Guide, v5.3.1
Chapter
5. Select Multicast from the Adv. Address pull-down menu.
6. Modify the default value in the Min. Advertisement
Interval (sec.) field and enter the minimum time interval
that passes before the host contacts the switch.
7. Modify the default value in the Max. Advertisement
Interval (sec.) field and enter the maximum time interval
that passes before the host contacts the switch.
8. Modify the default value in the Advertisement Life Time
(sec.) field, and enter a duration, in seconds, of the IRDP
advertisement.
9. Click APPLY to save your changes, or CANCEL to restore
previous settings.
10. Select Global Configuration from the Routing > IP >
Configuration group on the Web Agent window. The IP
Global Configuration dialog box opens (see Figure 6-61).
11. Select Enable the IP Multicast Forwarding field
pull-down menu.
12. Click APPLY to save your changes, or CANCEL to restore
previous settings.
Using the CLI
To enable IRDP on an interface using the CLI, enter the following
command in Enable/Configure/Interface mode:
(config-if:)# ip irdp
Refer to the Command Reference Guide for the Avaya P550R, P580, P880,
and P882 Multiservice Switches, Version 5.3.1 for details about this
command.
