Avaya P550R, P580, P880, and P882 Multiservice Switch User Guide, v5.3.1 15-17
Configuring AppleTalk Routing
Figure 6-131. Add AppleTalk NBP Filter Dialog Box
3. Refer to Table 6-85 to configure the Add AppleTalk NBP
filter dialog box.
4. Click CREATE to add your new static route, or CANCEL to
restore previous settings.
Using the CLI
To create an NBP filter using the CLI, enter the following command
from Interface mode:
(config-if :)# appletalk access-
list nbp
Refer to the Command Reference Guide for the Avaya P550R, P580, P880,
and P882 Multiservice Switches, v5.3.1 for details about this command.
Table 6-85. AppleTalk NBP Filter Parameters
Parameter Definition
Access List Enter the access list number to be associated with the
NBP filter. Valid values are 600-631.
Name Enter the name of the NBP name object to be filtered.
Type Select the type of filtering. The options include:
• Deny
• Permit
Interface Select the interface(s) to apply this filter to.
