Avaya P550R, P580, P880, and P882 Multiservice Switch User Guide, v5.3.1 15-25
Configuring AppleTalk Routing
Figure 6-137. AppleTalk Global Statistics Dialog Box
2. Refer to Table 6-87 for information about the AppleTalk
Global Statistics dialog box parameters.
Table 6-87. AppleTalk Global Statistical Dialog Box Parameters
Parameter Number of...
Echo Req Tx Echo requests transmitted.
Echo Reply Rx Echo replies received.
Echo Req Rx Echo requests received.
DDP Output Counter DDP packets sent from this node.
DDP Output Short DDP packets sent using the short format.
