Page 294
Not approved by Document Control. For review only.
Allied Telesis
Command Line Interface User’s Guide
Default Configuration
This command has no default configuration.
Command Mode
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
MAC based VLAN rules cannot contain overlapping ranges on the same interface.
The priority between VLAN classification rules is:
• MAC based VLAN (Best match between the rules)
• PVID
The interface must be in General Mode to configure a MAC-based classification rule.
Example
The following example sets a mac-based classification rule.
map mac macs-group
The map mac macs-group VLAN Configuration mode command maps a MAC address or a range of MAC
addresses to a group of MAC addresses. Use the no form of this command to delete a map.
Syntax
map mac mac-address {prefix-mask | host} macs-group group
no map mac mac-address {prefix-mask | host}
• mac-address — Specifies the MAC address to be entered to the group.
• prefix-mask — Specifies the Mask bits. The format is the MAC address format.
• host — Specifies all 1’s mask.
• group — Specifies the group number. (Range: 1-2147483647)
Default Configuration
This command has no default configuration.
Command Mode
VLAN Configuration mode
User Guidelines
There are no user guidelines for this command.
console(config)# vlan database
console(config-vlan)# map mac 00:08:78:32:98:78 9 macs-group 1
interface ethernet g17
console(config-vlan)# exit
console(config)# interface ethernet 1/g17
console(config-if)# switchport mode general
console(config-if)# switchport general map macs-group 1 vlan 2
