Command line interface commands



64

NOTE:

For XP12000/XP10000/SVS200, logical units cannot be created in array groups with

chassis numbers from 65 to 96. Array groups with chassis numbers from 65 to 96 are indicated as
V-VOLs.

NOTE:

For XP24000/XP20000, logical units cannot be created in array groups with chassis

numbers from 65 to 96, or from 16485 to 16516. Array groups with chassis numbers from 65 to
96, or from 16485 to 16516 are indicated as V-VOLs.

NOTE:

For XP24000/XP20000, XP12000/XP10000/SVS200, XP1024/XP128, and XP512/XP48,

the SSID must be set before an LDEV and LU are created. For details about the SSID, see the
manual for each storage subsystem.

Format for XP512/XP48, XP1024/XP128:

hdvmcli [

URL] AddLogicalUnit [options] serialnum=serial-number model=model

{chassis=

chassis-number groupnum=array-group-number|arraygroupname=array-group-name}

capacity=

capacity-of-the-logical-unit [emulation=emulation-type] [devnum=logical-unit-device-

number] [lusubinfo=LDEV] [format={none|normal}]

Format for XP24000/XP20000:

hdvmcli [

URL] AddLogicalUnit [options] serialnum=serial-number model=model

{chassis=

chassis-number groupnum=array-group-number|arraygroupname=array-group-name}

capacity=

capacity-of-the-logical-unit [emulation=emulation-type] [devnum=logical-unit-device-

number] [lusubinfo=LDEV] [format={none|normal|quick}] [capacitytype={KB|block}]

Format for XP12000/XP10000/SVS200:

hdvmcli [

URL] AddLogicalUnit [options] serialnum=serial-number model=model

{chassis=

chassis-number groupnum=array-group-number|arraygroupname=array-group-name}

capacity=

capacity-of-the-logical-unit [emulation=emulation-type] [devnum=logical-unit-device-

number] [lusubinfo=LDEV] [format={none|normal}] [capacitytype={KB|block}]

Table 4-16

AddLogicalUnit command parameters

Parameter Name Status

Description

serialnum

Required

Serial number of the storage array where the LU is added

model

Required

Model of the storage array where the LU is added

chassis

Optional

Number of chassis for the array group where the LU is added

If you specify this parameter, make sure that groupnum is also specified.

NOTE:

Either specify chassis and groupnum at the same time, or

specify arraygroupname. Also, make sure that the combination of
chassis

and groupnum is not specified at the same time as

arraygroupname

. This might cause an error to occur.

groupnum

Optional

Group number of the array group where the LU is added

If you specify this parameter, make sure that groupnum is also specified.

NOTE:

Either specify chassis and groupnum at the same time, or

specify arraygroupname. Also, make sure that the combination of
chassis

and groupnum is not specified at the same time as

arraygroupname

. This might cause an error to occur.

arraygroupname

Optional

Display name for the array group where the LU is added

When this parameter is specified, do not specify chassis or groupnum.

NOTE:

Either specify chassis and groupnum at the same time, or

specify arraygroupname. Also, make sure that the combination of
chassis

and groupnum is not specified at the same time as

arraygroupname

. This might cause an error to occur.
