Command line interface commands



255

Table 4-127

Items output when instance is Pool

Attribute Description

controllerID

ID of the disk controller for the journal pool
One of the following values is output:
For XP24000/XP20000:

XP Continuous Access Journal Software: Logical DKC number

For other cases: -1

-1

is output for other storage subsystems.

poolType

Indicates the pool type.

The value output depends on the poolFunction value.

When poolFunction is 3:

-1

: None

When poolFunction is 4:

-1

: None

0

: Main XP Continuous Access Journal Software journal group (M-JNL)

1

: Remote XP Continuous Access Journal Software journal group (R-JNL)

2

: Initialized XP Continuous Access Journal Software journal group

3

: Journal group of XP Continuous Access Journal Software or XP

Continuous Access Journal Software for mainframe that has no journal
volumes

8

: Main XP Continuous Access Journal Software for mainframe journal group

(M-JNL)

9

: Remote XP Continuous Access Journal Software for mainframe journal

group (R-JNL)

10

: Initialized XP Continuous Access Journal Software for mainframe journal

group

When poolFunction is 5:

-1

: None

32

: THP pool

status

Status of the journal group
For XP24000/XP20000, one of the following values is output when
poolFunction

is 5:

0

: Normal

16

: Blocked

17

: Over threshold

-1

is output for other cases.

threshold

Value set by the user as the usage rate threshold for the journal pool

For XP24000/XP20000, when poolFunction is 5, the value set by the user as
the usage rate threshold for the THP pool is output.

-1

is output for other cases.

threshold2

Value determined by the storage subsystem to be the usage rate threshold for the
journal pool

For XP24000/XP20000, when poolFunction is 5, the value determined by the
storage subsystem to be the usage rate threshold for the THP pool is output.

-1

is output for other cases.
