Command line interface commands
177
Command execution example:
hdvmcli AddWWNForHostStorageDomain -o "D:\logs\XP1024
AddWWNForHostStorageDomain.log" "serialnum=10001" "model=XP1024" "port=1"
"domain=1" "wwn=22.33.44.55.44.55.44.33,11.33.22.33.44.33.22.22"
Command execution result:
RESPONSE:
An instance of StorageArray
.
. (Attributes of StorageArray are omitted here)
.
List of 1 HostStorageDomain elements:
An instance of HostStorageDomain
objectID=*****
portID=1
domainID=1
hostMode=Standard
displayName=CL1-B-1
domainType=0
nickname=HCMD0103
List of 2 WWN elements:
An instance of WWN
WWN=22.33.44.55.44.55.44.33
nickname=Jane
An instance of WWN
WWN=11.33.22.33.44.33.22.22
nickname=Jone
*****
: The value is encoded by the CLI.
4-6-4 AddWWNForLun
AddWWNForLun
secures a path by assigning a WWN to it (see
).
A user who has only View permission cannot execute this command. A user to whom a user-defined
resource group is assigned, and who also has Modify permission, can execute this command for
any resources.
NOTE:
When AddWWNForLun secures a path, XP LUN security is automatically enabled. Make
sure that the I/Os of the target port are stopped.
NOTE:
This command supports only the XP512/XP48 subsystems.
Table 4-68
AddWWNForLun command parameters
Parameter Name
Status
Description
serialnum
Required
Serial number of the port's storage array
model
Required
Model of the port's storage array
port
Optional Port
number
NOTE:
Specify either port or portname. Do not specify both
parameters at the same time. This might cause an error to occur.
portname
Optional Port
name
NOTE:
Specify either port or portname. Do not specify both
parameters at the same time. This might cause an error to occur.
