OPERATION
97
Create a Program Chain
Note
Before creating a program chain, make sure a
number of programs have already been saved.
These will be used to create the program chain.
Chain Setting
Display Overview
Select
Start
LOAD RS232 03/Sep/2012
Off
P03 Off
P02 Off
P04
P01
Start
Off
P01
Program Chain Set
Starting program
for the chain
Recall
Default
Previous
Menu
Operation 1. Press FUNC > Program[F1] > Chain[F1].
 It may be necessary to load the programs from
Setup memory if they were not created in the
current session.
2. If Start is not already selected, press Select
Start[F1] and select which program will be used
to start the program chain.
Start: P01 ~ P16
3. Select P01 and choose which program will be
linked to P01.
 Selecting OFF will end the chain after P01.
 Selecting P01 will create an infinite chain.
 Chains need not be linked in sequential order.
P01: OFF, P01 ~ P16
