OPERATION
101
Sequence 1
STEP 01
STEP 02
:
STEP N
Sequence 2
STEP 01
STEP 02
:
STEP N
Sequence 10
STEP 01
STEP 02
:
STEP N
Start Sequence
:
:
:
:
Description Normal Sequence configuration is split into
Timing Edit configuration and Data Edit
configuration.
Timing Edit configuration is used to configure
the actual sequences, such as mode, range,
loops and chains.
Data Edit configuration is used to create the
actual steps used in each sequence.
See below for a description of each.
Timing Edit
Overview A Normal Sequence contains the following
timing settings for each sequence:
Setting Setting Range Description
Start S01 ~ S10 Sets which sequence is used
to start a chain of Normal
Sequences.
Seq.No S01 ~ S10 Sets the current sequence to
edit.
