PEL-3000 User Manual
108
Running a Normal Sequence
Description A load created with the Normal Sequence
function is run the same way as a normal load.
Operation 1. Press FUNC > Sequence[F1] > Normal Sequence
[F1].
2. Turn normal sequence mode on by setting
N. Seq.[F1] to On.
 NSEQ
will appear at the top of the display when
N. Seq. is On.
3. Turn the load on.
 The normal sequence/chain starts immediately.
 The
NSEQ
icon turns orange when the load is
turned on.
4. When a normal sequence/chain is running, the
screen displays which sequence, step and loop
are currently active.
 Sequences can be paused by pressing Pause[F1]
and resumed again by pressing Continue[F1].
 If no steps have been created ―No N.Seq.‖ will
be displayed on the screen.
 “Sequence Complete‖ will be displayed at the end
of the sequence.
