APPENDIX
201
Slew Rate Setting Range (CR Mode)
H Range
250uA/us~250mA/us 500uA/us~500mA/us 1.6mA/us~1.6A/us
M Range 25uA/us~25mA/us 50uA/us~50mA/us 160uA/us~160mA/us
L Range 2.5uA/us~2.5mA/us 5uA/us~5mA/us 16uA/us~16mA/us
Slew Rate Resolution
Resolution
1mA 2mA 6mA
Setting 250mA/us~2.5A/us 500mA/us~5A/us 1.6A/us~16A/us
Resolution 100uA 200uA 600uA
Setting 25mA/us~250mA/us 50mA/us~500mA/us 160mA/us~1.6A/us
Resolution 10uA 20uA 60uA
Setting 2.5mA/us~25mA/us 5mA/us~50mA/us 16mA/us~160mA/us
Resolution 1uA 2uA 6uA
Setting 250uA/us~2.5mA/us 500uA/us~5mA/us 1.6mA/us~16mA/us
Resolution 100nA 200nA 600nA
Setting 25uA/us~250uA/us 50uA/us~500uA/us 160uA/us~1.6mA/us
Resolution 10nA 20nA 60nA
Setting 2.5uA/us~25uA/us 50uA/us~50uA/us 160uA/us~1.6mA/us
Slew Rate Accuracy of Setting *1
±(10% of set + 5us)
*1 Time to reach from 10 % to 90 % when the current is varied from 2 % to 100 %
(20 % to 100 % in M range) of the rated current.
Current Setting Range
H Range
0A~35.7A 0A~71.4A 0A~214.2A
M Range 0A~3.57A 0A~7.14A 0A~21.42A
L Range 0A~0.357A 0A~0.714A 0A~2.142A
Current Resolution
H Range
1mA 2mA 10mA
M Range 0.1mA 0.2mA 1mA
L Range 0.01mA 0.02mA 0.1mA
Current Accuracy
±0.4% F.S
Resistance Operating range
H Range
22S~400uS
(45.455mΩ~2.5kΩ) 44S~800uS
(22.727mΩ~1.25kΩ) 133.332S~2.4mS
(7.5mΩ~416.666Ω)
M Range 2.2S~40uS
(454.55mΩ~25kΩ) 4.4S~80uS
(227.27mΩ~12.5kΩ) 13.3332S~2420uS
(75mΩ~4.1666kΩ)
L Range 0.22A~4uS
(4.545Ω~250kΩ) 0.44S~8uS
(2.2727Ω~125kΩ) 1.33332S~24uS
(750mΩ~41.666kΩ)
Resistance Resolution
H Range
400uS 800uS 2.424mS
M Range 40uS 80uS 242.4uS
L Range 4uS 8uS 24.24uS
