Pulse Width Modulation
For pulse width modulation the instantaneous voltage of the
modulating waveform determines the width of the pulse waveform.
Only one mode of modulation can be enabled at any one time. If
PWM is enabled, any other modulation mode will be disabled.
Likewise, burst and sweep modes cannot be used with PWM and
will be disabled when PWM is enabled.
