AFG-3000 Series User Manual
248
Note The Trig out signal depends on the selected trigger
source.
Trigger Source Description
Immediate
A square wave is output from the
Trig out terminal with a 50% duty
cycle at the start of every sweep.
External Trigger Output is disconnected.
Manual A pulse (>1 us) is output from the
Trig out terminal at the start of each
sweep.
Syntax OUTPut[1]:TRIGger:SLOPe {POSitive|NEGative}
Example OUTP1:TRIG:SLOP NEG
Sets the Trig out signal as negative edge.
Query Syntax OUTPut[1]:TRIGger:SLOPe?
Return Parameter POS Positive edge
NEG Negative edge
Example OUTP1:TRIG:SLOP?
NEG
The Trig out signal is set to negative edge.
OUTPut[1]:TRIGger
Source Specific
Command
Description Turns the trigger out signal on or off from the Trig
out terminal on the rear panel. When set to on, a
trigger signal (TTL) is output at the start of each
pulse. The default is setting is off.
Syntax OUTPut[1]:TRIGger {OFF|ON}
Example OUT OUTP1:TRIG ON
Enables the Trig out signal.
Query Syntax OUTPut[1]:TRIGger?
Return Parameter 0 Disabled
1 Enable
