AFG-3000 Series User Manual
14
The UTIL key is used to access the
save and recall options, set the
remote interface (USB, GPIB,
RS232), use DSO link, update and
view the firmware version, access
the calibration options, output
impedance settings, set the
language and access the help
menu.
ARB is used to set the arbitrary
waveform parameters.
The MOD, Sweep and Burst keys
are used to set the modulation,
sweep and burst settings and
parameters.
Preset The preset key is used to recall a
preset state.
Output key The Output key is used to turn on
or off the waveform output.
Output
indicators When an Output indicator is
green, it indicates that the output
is active.
