REMOTE INTERFACE
207
0~4.99V (50Ω)
Example SOUR1:APPL:SQU 2KHZ,MAX,MAX
Sets frequency to 2kHz and sets the amplitude and
offset to the maximum.
SOURce[1]:APPLy:RAMP
Source Specific
Command
Description Outputs a ramp wave from the selected channel
when the command has executed. Frequency,
amplitude and offset can also be set. The
symmetry is set to 100%.
Syntax SOURce[1]:APPLy:RAMP [ [,
[,] ]]
Parameter 1μHz~1MHz
< amplitude > 10mV~10V (50Ω)
0~4.99V (50Ω)
Example SOUR1:APPL:RAMP 2KHZ,MAX,MAX
Sets frequency to 2kHz and sets the amplitude and
offset to the maximum.
SOURce[1]:APPLy:PULSe
Source Specific
Command
Description Outputs a ramp wave from the selected channel
when the command has executed. Frequency,
amplitude and offset can also be set.
Note The PW settings from the SOURce[1]:PULS: WIDT
command are preserved. Edge and pulse width
may be adjusted to supported levels.
Repetition rates will be approximated from the
frequency. For accurate repetition rates, the period
should be adjusted using the
SOURce[1]:PULS:PER command
Syntax SOUR[1]:APPLy:PULSe [ [,
[,] ]]
