GETTING STARTED
11
G
ETTING STARTED
The Getting started chapter introduces the
function generator’s main features, appearance, set
up procedure and power-up.
Main Features
Model name Frequency bandwidth
AFG-3081 80MHz
AFG-3051 50MHz
Performance  DDS Function Generator series
 1μHz high frequency resolution maintained at
full range
 1ppm frequency stability
 Full Function Arbitrary Waveform Capability
200 MSa/s sample rate
100 MSa/s repetition rate
1 M-point waveform length
16-bit amplitude resolution
Ten 1M waveform memories
True waveform output to display
User define output section
User defined marker output section
D W R (Direct Waveform Reconstruction)
capability
Waveform editing capability sans PC
N Cycle and Infinite output mode selectable
