AFG-3000 Series User Manual
126
6. Use the selector keys and
scroll wheel or number pad
to enter the GPIB address.
/
7. Press F5 (Done) to confirm
the GPIB address.
Range GPIB address 1~30
RS232 Interface
Background When using the RS232 interface, a baud rate must
be specified.
Panel Operation 1. Press the UTIL key.
2. Press F2 (Interface).
3. Press F2 (RS-232).
4. Press F1 (Baud Rate).
5. RS232 Baud Rate will become highlighted in
the parameter window.
