MODULATION

113

3. Press F2 (Infinite).

Note

Infinite burst in only available when using manual
triggering.

Above 25MHz, Infinite burst is only available with
square and sine waveforms.

Burst Period

The burst period is used to determine the time between the start of
one burst and the start of the next burst. It is only used for internally
triggered bursts.

Panel Operation

1. Press the Burst key.

2. Press F1 (N Cycle).

3. Press F4 (Period).

4. The Period parameter will become highlighted

in the Waveform Display area.
