AFG-3000 Series User Manual
104
Marker Frequency
The marker frequency is the frequency at which the marker signal goes low
(The marker signal is high at the start of each sweep). The marker signal is
output from the MARK terminal on the rear panel. The default is 550 Hz.
Panel Operation 1. Press the SWEEP key.
2. Press F6 (More).
3. Press F3 (Marker).
4. Press F2 (ON/OFF) to
toggle the Marker
5. Press F1 (Freq) to select the
marker frequency.
6. The Freq parameter will become highlighted
in the Waveform Display area.
7. Use the selector keys and
scroll wheel or number pad
to enter the frequency.
/
