AFG-3000 Series User Manual
180
Load a Waveform from USB
Panel Operation 1. Press the ARB key.
2. Press F5 (Load).
3. Press F2 (USB).
4. Use the scroll wheel to
choose a file name.
5. Press F1 (Select) to select the
file to load.
6. Press F3 (To) to choose the
starting point for the loaded
waveform.
7. The “Load To” property will become
highlighted in red.
8. Use the selector keys and
scroll wheel or number pad
to enter the starting point.
/
9. Press F5 (Enter) to confirm
the Start point.
10. Press F5 (Done).
