APPENDIX
299
Direction Up or Down
Start/Stop Freq 100 μHz to 50 MHz 100 μHz to 80 MHz
Sweep Time 1 ms to 500 s
Trigger Single, External, Internal
Marker Falling edge of Mark signal
(Programmable frequency)
Source Internal / External
Burst
Waveforms Sine, Square, Triangle, Ramp
Frequency 1 μHz to 50
MHz(4)
1 μHz to 80
MHz(4)
Burst Count 1 to 1000000 cycles or Infinite
Start/Stop Phase -360.0 to +360.0
Internal Period 1 ms to 500 s
Gate Source External Trigger
Trigger Source Single, External or Internal Rate
Trigger Delay N-Cycle, Infinite 0s to 85 s
External Modulation Input
Type For AM, FM, Sweep, PWM
Voltage Range ± 5V full scale
Input Impedance 10kΩ
Frequency DC to 20kHz
External Trigger Input
Type For FSK, Burst, Sweep
Input Level TTL Compatibility
Slope Rising or Falling (Selectable)
Pulse Width >100ns
Input Impedance 10kΩ, DC coupled
Latency Sweep <10us (typical)
Burst <100ns (typical)
Jitter Sweep 2.5 us
Burst 1 ns; except pulse, 300 ps
Modulation Output
Type For AM, FM, Sweep, PWM
Amplitude Range ≥1Vpp
Impedance > 10kΩ typical (fixed)
Trigger Output
Type For Burst, Sweep
Level TTL Compatible into 50Ω
Pulse Width >450 ns
Maximum Rate 1 MHz
Fan-out ≥4 TTL load
Impedance 50Ω Typical
Marker Output
Type For ARB, Sweep
