AFG-3000 Series User Manual
34
Input: N/A 3. Press 5 + Cyc (F5).
4. Press Burst, N Cycle
(F1), Period (F4).
5. Press 1 +0 + msec
(F2).
6. Press Burst, N Cycle
(F1), Phase (F3).
7. Press 0 + Degree
(F5).
8. Press Burst, N Cycle
(F1), TRIG Setup
(F5), INT (F1).
9. Press Burst, N Cycle
(F1), TRIG Setup
(F5), Delay (F4).
10. Press 1 + 0 + uSEC
(F2).
11. Press Burst, N Cycle
(F1), TRIG Setup
(F5), TRIG out (F5),
ON/OFF (F3), Rise
(F1).
12. Press the output
key.
