AFG-3000 Series User Manual
268
Parameter Start address*: 0~1048,576
Length*: 0 ~ 1048,576
Scale: ±32767
* Start + Length ≤ 1,048,576
Example SOUR1:ARB:BUIL:SQU 1000, 1000, 100
Creates a square wave 1000 points in length with a
scale of 100 and a start address of 1000.
SOURce[1]:ARB:BUILt:PULSe
Source Specific
Command
Description Creates a pulse wave with a specified frequency
and duty.
Syntax SOURce[1]:ARB:BUILt:PULSe
[[,]]
Parameter 1pHz~500kHz*
0.0001%~99.9999%
*Frequency Resolution Duty Resolution
1pHz~5Hz 1pHz 0.0001%
>5Hz~50Hz 1uHz 0.0001%
>50Hz~500Hz 10uHz 0.001%
>500Hz~5kHz 100uHz 0.01%
>5kHz~50kHz 1mHz 0.1%
>50kHz~500kHz 10mHz 1%
Example SOUR1:ARB:BUIL:PULSe +1.00000002E+03,
+1.002E+01
Creates a 1000.0002Hz pulse wave with a 10.02%
duty cycle.
