AFG-3000 Series User Manual
266
SOURce[1]:ARB:EDIT:LINE
Source Specific
Command
Description Edit a line on the arbitrary waveform. The line is
created with a starting address and data point and
a finishing address and data point.
Note A waveform/waveform segment cannot be
deleted when output.
Syntax SOURce[1]:ARB:EDIT:LINE
[[,[,[,]]]]
Parameter Address of data point1:
0~1,048,576
Value data2: ± 32,767
Address of data point2:
0~1,048,576
Value data2: ± 32,767
Example SOUR1:ARB:EDIT:LINE 40, 50, 100, 50
Creates a line on the arbitrary waveform at 40,50 to
100,50.
SOURce[1]:ARB:EDIT:PROTect
Source Specific
Command
Description Protects a segment of the arbitrary waveform from
deletion or editing.
Syntax SOURce[1]:ARB:EDIT:PROTect [[,]]
Parameter Start address: 0~1048,576
0 ~ 1048,576
Example SOUR1:ARB:EDIT:PROT 40, 50
Protects a segment of the waveform from address
40 for 50 data points.
SOURce[1]:ARB:EDIT:PROTect:ALL
Source Specific
Command
