AFG-3000 Series User Manual
260
SOURce[1]:BURSt:OUTPut:TRIGger:SLOPe
Source Specific
Command
Description Sets or queries the trigger edge of the trigger
output signal. The signal is output from the trigger
out terminal on the rear panel. The default trigger
output slope is positive.
Note The trigger output signal on the rear panel
depends on the burst trigger source or mode:
Immediate 50% duty cycle square wave is
output at the start of each burst.
External Trigger output disabled.
Gated mode Trigger output disabled.
Manual A >1 ms pulse is output at the
start of each burst.
Syntax SOURce[1]:BURSt:OUTPut:TRIGger:SLOPe
{POSitive|NEGative}
Parameter POSitive Rising edge.
NEGative Falling edge.
Example SOUR1:BURS:OUTP:TRIG:SLOP POS
Sets the trigger output signal slope to positive
(rising edge).
Query Syntax SOURce[1]:BURSt:OUTPut:TRIGger:SLOPe?
Return Parameter POS Rising edge.
NEG Falling edge.
Example SOUR1:BURS:OUTP:TRIG:SLOP?
POS
The trigger output signal slope to positive.
