The offset is also determined by the output
termination (50Ω or high impedance). If the offset
has been set and the output termination has
changed from 50Ω to high impedance, the offset
will double. Changing the output termination from
high impedance to 50Ω will half the offset.
SOURce[1]:APPLy:SINusoid
Source Specific
Command
Description Outputs a sine wave from the selected channel
when the command has executed. Frequency,
amplitude and offset can also be set.
Syntax
SOURce[1]:APPLy:SINusoid [
[, [,] ]]
Parameter 1μHz~80MHz(3081)/
50MHz(3051)
< amplitude > 10mV~10V (50Ω) (3.536
Vrms)
0~4.99V (50Ω)
Example SOUR1:APPL:SIN 2KHZ,MAX,MAX
Sets frequency to 2kHz and sets the amplitude and
offset to the maximum.
SOURce[1]:APPLy:SQUare
Source Specific
Command
Description Outputs a square wave from the selected channel
when the command has executed. Frequency,
amplitude and offset can also be set. The duty
cycle is set to 50%.
Syntax
SOURce[1]:APPLy:SQUare [ [,
[,] ]]
Parameter 1μHz~80MHz(3081)/
50MHz(3051)
< amplitude > 10mV~10V (50Ω)
