AFG-3000 Series User Manual
300
Level TTL Compatible into 50Ω
Fan-out ≥4 TTL load
Impedance 50Ω Typical
Store/Recall 10 Groups of Setting Memories
Interface GPIB, RS232, USB
Display 4.3 inch TFT LCD
480 × 3 (RGB) × 272
System Characteristics
Configuration
Times (typical)
Function Change:
Standard---->102ms
Pulse-------->660ms
Built-In Arb->240ms
Frequency Change: 24ms
Amplitude Change: 50ms
Offset Change: 50ms
Select User Arb: < 2s for 1M points
Modulation Change: < 200ms
Arb Download
Times
(typical) Binary Code ASCII Code
GPIB/RS232
(115 Kbps)
USB Device USB Host
1M points 189 sec 34 sec 70 sec
512K points 95 sec 18sec 35 sec
256K points 49 sec 9 sec 18 sec
64K points 16 sec 3 sec 6 sec
16K points 7 sec 830 ms 1340 ms
8K points 6 sec 490 ms 780 ms
4K points 6 sec 365 ms 520 ms
2K points 5 sec 300 ms 390 ms
General Specifications
Power Source AC100~240V, 50~60Hz
Power
Consumption 65 VA
Operating
Environment
Temperature to satisfy the specification :
18 ~ 28˚C
Operating temperature :
0 ~ 40˚C
Relative Humidity:
≤ 80%, 0 ~ 40˚C
≤ 70%, 35 ~ 40˚C
Installation category： CAT Ⅱ
Operating
Altitude 2000 Meters
