SECONDARY SYSTEM FUNCTION
SETTINGS
129
System and Settings
There are a number of miscellaneous settings such as language
options, output impedance settings, DSO link, and firmware settings
that can be configured.
Viewing and Updating the Firmware Version
Panel Operation
1. Press the UTIL key.
2. Press F3 (Cal.).
3. Press F2 (Software).
View Version 4. To view the firmware
version, press F1(Version)
The version information will be shown on screen:
Instrument, Version, FPGA Revision, Bootload version
Update Firmware 5. To update the firmware,
insert a USB flash drive with
a firmware file in the USB
host drive. Press F2
(Upgrade).
Note
The firmware file (*.bin) must be located in a directory
named UPGRADE, directly off the USB root directory.
UPGRADE must be all capitals.
