AFG-3000 Series User Manual
296
AFG-3000 Series Specifications
The specifications apply when the function generator is powered on
for at least 30 minutes under +20°C~+30°C.
Waveforms AFG-3051 AFG-3081
Sine, Square, Ramp, Pulse, Noise, DC,
Sin(x)/x, Exponential Rise, Exponential
Fall, Negative Ramp
Arbitrary Waveforms
ARB Function Built in
Sample Rate 200 MSa/s
Repetition Rate 100MHz
Waveform Length 1M points
Amplitude
Resolution
16 bits
Non-Volatile
Memory Ten 1M waveforms(1)
User defined
Output Section
Any section from 2 to 1M points
User defined
Mark Output Any section from 2 to 1M points
Output mode 1 to 1048575 cycles or Infinite mode
selectable
Frequency Characteristics
Range Sine 50MHz 80MHz
Square 50MHz 80MHz
Triangle, Ramp 1MHz
Resolution 1μHz
Accuracy Stability ±1 ppm 0 to 50˚C
±0.3 ppm 18 to 28˚C
Aging ±1 ppm, per 1 year
Tolerance ≤1 μHz
Output Characteristics(2)
Amplitude Range 10 mVpp to 10 Vpp( into 50Ω)
20 mVpp to 20 Vpp(open-circuit)
Accuracy ± 1% of setting ±1 mVpp
(at 1 kHz,>10 mVpp)
Resolution 0.1 mV or 4 digits
