SierraFC M8‐4 Protocol Analyzer User Manual

57

Easy Mode (Pre‐Defined Setups)

 Teledyne   LeCroy

Generic Link Service ‐ Request, Reply

Double‐click Generic Link Service ‐ Request, Reply in the Pattern window to open the
Add Generic Link Service ‐ Request, Reply Pattern dialog.

Figure 2.26: Generic Link Service-Request, Reply Pattern Dialog

The format can be Binary or Hexadecimal.

Click the dropdown lists to select a GS_Type, GS_Subtype, Command Type, and
Command.
