SierraFC M8‐4 Protocol Analyzer User Manual 19
Expandability Teledyne LeCroy
Note: Click Refresh Device List to display all the devices on the network.
The Select Device dialog displays the following buttons:
Set Alias Name
Click Set Alias Name to display the Set device alias name dialog as shown below.
Figure 1.10: Set Device Alias Name Dialog
Disconnect
Click Disconnect to disconnect a device.
Add Device...
Click Add Device to add a device with a static IP address.
Figure 1.11: Add Device with Static IP Dialog
Remove Device
Click Remove Device to remove a previously added device.
IP Settings...
Click IP Setting to reset IP settings of a device. The following IP Setting dialog displays.
Press Tab to move between fields.
Figure 1.12: IP Setting Dialog
