Teledyne LeCroy Settings in Advanced Mode
284 SierraFC M8‐4 Protocol Analyzer User Manual
The following table lists supported Actions in Advanced Mode. Note that some of these
Actions only apply to creating sequences.
TABLE 4.5: Test State Actions in Advanced Mode
Action Description
Analyzer Trigger The Jammer sends a trigger to the
Analyzer.
Beep Emits audible sound of duration selectable
via drop‐down list.
Branch to
Existing State
1 Go to a state in this sequence that is
already defined.
1
New State
1 Go to a state in this sequence that is not
yet defined (you need to define it).
1
Capture Data Dword Captures a data dword into one of four
registers.
DWORD Jam
Replace Replace DWORD
Frame Jam
Insert DWORD
Inside Frame Allows to insert up to 14 dwords inside the
frame, at the specified offset or at the
“current” dword, meaning the dword that
caused the Event.
Modify [Keep
Length] Allows to manipulate each dword in the
header, with the selected Action (click on
Pass though to get a drop‐down list).
Remove [Replace
with IDLE] Removes the whole frame.
Replace Replaces the whole frame with the
selected frame.
Truncate Removes some of the payload, as specified
in the Frame Length.
Inject General Error Invalid 10‐bit‐code
Error
Injects invalid 10b code into the line.
Running Disparity
Error Injects a Running Disparity (RD) error into
traffic.
Insert Insert DWORD Allows to insert up to 14 dwords inside the
frame, at the specified offset or at the
“current” dword, meaning the dword that
caused the Event.
Insert Frame Allows to insert a whole frame as specified
from the list of available frames.
