Bus Conditions Report
To display the Bus Conditions Report, click the Bus Conditions tab. The Bus Conditions
Report displays the conditions of the bus. The following information is displayed in this
report:
 Port: The ports that are selected
 Type: All, Custom, Disconnect, Connect
 Count: All, Custom, or a number of occurrences
 %: of total count
Note: The Bus Conditions tab appears only if there are any changes to the bus condition in the trace.
Figure 3.34: Bus Conditions Statistical Report
