SierraFC M8‐4 Protocol Analyzer User Manual 215
Statistical Report Toolbar Teledyne LeCroy
Figure 3.45: Statistical Report Column Setting
Link With Sample View
When you select a type on any page of the Statistical Report, a set of navigation buttons
allows you to examine each instance of that type in the Sample Viewer.
The Jump to Previous button goes to the previous instance of the
selected type in the Sample Viewer.
The Jump to Next button goes to the next instance of the selected
type in the Sample Viewer.
The Jump to Specific button goes to the instance specified as N of M
items on the Statistical Report toolbar.
The Move drop‐down list moves to the X‐Cursor, Y‐Cursor, or None.
