WaveRunner 6 Zi and 12-Bit HRO
30 922136-00 Rev A

History is turned Off and the History dialog is Closed.
On the History dialog, a Capacity control is provided.
Note : A default value for the Capacity control is generated based on your
instrument's specific Acquisition Memory Setting (it also varies based on specific
setups, configurations, and settings at any given time).
The Zoom and Table buttons are used as described in The WavePilot
Control Area and The SuperKnob Overview
(on page 25 ) .
L
AB
N
OTEBOOK
When first pressing the LabNotebook function button, the LabNotebook
dialog is shown. The button toggles between opening and closing the
LabNotebook dialog - unless you already have LabNotebook entries stored.
With LabNotebook entries already stored subsequent presses of the
LabNotebook function button:

opens the LabNotebook dialog and your first My Notebook Entry is
shown on the display area in Preview mode.

closes the LabNotebook dialog and the My Notebook Entry preview.
As mentioned, with LabNotebook entries already stored a subsequent
press of the LabNotebook function button shows the preview along with
the dialog. You can then turn the SuperKnob to move through entries
shown in My Notebook Entries on the LabNotebook dialog. Pushing the
SuperKnob performs a Flashback (Recall) of the stored entry selected in the
My Notebook Entries on the LabNotebook dialog.
Note : Zoom and Table buttons are not used for LabNotebook.
S
PECTRUM
When first pressing the Spectrum function button, the Spectrum dialog is
shown with table data showing in a column to the left of the main display
area. Subsequent presses of the Spectrum function button produce the
following results:

Spectrum Analysis is turned Off and the SpectrumAnalyzer dialog is
Closed.

Spectrum Analysis is turned On and you click Close on the
SpectrumAnalyzer dialog or open a different dialog (say, the Zoom
dialog), and then click the Spectrum function button, the
SpectrumAnalyzer dialog is Opened.
