Getting Started Manual

922136-00 Rev A

13

B

Numbered labels on the following I/O Panel image correspond with
descriptions on the following table.

Number and Description

1. USB488

Connection

2. USB A

Connections

3. Ethernet Port

4. Microphone

Connection

5. Speaker

Connection

6. Line In

Connection

7. External VGA

Monitor
Connection

Note

: Contact a system administrator when connecting to any internal LAN.
