Parameter Setup
1. Touch the parameter tab (Px) of an unused location or one that you
want to change.
2. Under Type, select a measurement type:
Measure On Waveforms applies measurements directly on
the waveform as indicated on the Source1 control.
Math On Parameters performs math (addition, subtraction,
multiplication, division) on parameters indicated on the
Source1 and Source2 controls.
Advanced Web Edit uses Teledyne LeCroy's Processing Web
for measurement setup. This feature, available with the
XWEB option, allows you to chain practically unlimited math
functions together for operation on your waveform measurements.
3. Touch inside the Source1 field and select a channel, math trace,
memory trace, or other waveform to be measured.
4. If you selected Measure On Waveforms, touch inside the Measure
field and select a parameter from the pop-up menu.
OR
If you selected Math On Parameters, touch inside the Math
Operator data entry field and select a math function from the pop-
up menu.
5. In the mini-dialog to the right of the main setup dialog, touch the
Gate tab to narrow the span of measurement - as covered in the
Measure Gate topic
(available in the online help files) .
6. Touch the Accept tab to define parameter values to be used in the
measurement - as covered in the Qualified Parameters topic
(available in the online help files) .
